APC Easy UPS On-Line SRV 6000VA/6kW RM 230V | 4U Rackmount | Pure Sine Wave | Intelligent Card Slot | LCD | Rail Kit Included | 2-Year Warranty | SRV6KRIRK

Documents

Click Here For Product Data Sheet

Product Description

APC Easy UPS On-Line SRV 6000VA/6kW RM 230V (SRV6KRIRK)

The APC Easy UPS On-Line SRV 6000VA/6kW RM 230V (SRV6KRIRK) is a high-capacity online uninterruptible power supply designed for IT professionals and network administrators who require dependable power protection for critical equipment. With a 6000VA/6000W capacity, double-conversion online topology, and pure sine wave output, it provides stable and conditioned power for servers, storage systems, networking equipment, telecommunications equipment, and other critical electronics.

The UPS uses double-conversion online technology to continuously condition incoming electrical power and provide regulated output power to connected equipment. The pure sine wave output is designed to support sensitive electronic equipment and critical IT loads during power disturbances and outages. Schneider Electric identifies the SRV series for applications including small data centers, manufacturing facilities, computer rooms, network storage devices, telecommunications, and healthcare IT.

The 4U rackmount design allows the SRV6KRIRK to be installed in compatible server racks while making efficient use of rack space. The product is supplied with a rail kit, simplifying rack installation. Schneider Electric’s official product page identifies the unit as a 4U rackmount UPS with the rail kit included.

The SRV6KRIRK uses a hard-wired 3-wire (1P+N+E) input and a hard-wired 3-wire (1P+N+E) output. This configuration is intended for higher-capacity installations where hard-wired electrical connections are appropriate. Schneider Electric’s specifications identify the input and output connections as hard-wired 3-wire configurations.

For UPS monitoring and management, the unit includes an intelligent card slot that supports an optional Network Management Card. Compatible network management options enable administrators to monitor and manage the UPS over a network and integrate it with centralized management platforms such as EcoStruxure IT or compatible third-party systems.

The built-in LCD interface provides an easy-to-read display for UPS status and operating information. Schneider Electric specifically highlights the LCD as providing detailed and accurate information about UPS status.

The UPS also features an ECO operating mode designed to provide high operating efficiency when the operating conditions allow it. Intelligent temperature-compensated battery charging helps optimize charging according to battery conditions and contributes to prolonged battery life.

The SRV6KRIRK also includes built-in automatic and manual bypass functionality. The bypass provides a path for maintaining power to the connected load if an internal UPS fault or error is detected, helping support continuity of operation.

The APC Easy UPS On-Line SRV 6000VA/6kW RM 230V is covered by a 2-year warranty for the UPS and built-in lead-acid battery, according to Schneider Electric’s product information for the SRV series.

Key Features

• 6000VA / 6000W rated power capacity
• 230V AC single-phase operation
• Double-conversion online UPS technology
• Pure sine wave output
• 4U rackmount design
• Rail kit included
• Hard-wired 3-wire (1P+N+E) input
• Hard-wired 3-wire (1P+N+E) output
• Intelligent card slot for optional Network Management Card
• LCD interface for UPS status monitoring
• ECO mode for improved operating efficiency
• Temperature-compensated battery charging
• Automatic and manual bypass
• Compatible with centralized UPS monitoring platforms
• 2-year UPS and battery warranty
