Easy UPS 3M 60kVA/60kW 400V 3:3 | External Batteries | 5×8 Start-Up | EcoStruxure Ready | 1-Year Warranty | E3MUPS60KHS
The Easy UPS 3M 60kVA/60kW 400V 3:3 UPS (E3MUPS60KHS) is a high-capacity three-phase online UPS designed to provide reliable power protection for small and medium data centers and other business-critical applications. It features double-conversion online technology, 60kVA/60kW capacity, 400V three-phase input and output, and an external battery system that allows the battery solution to be customized to the required runtime. The UPS includes 5×8 start-up service, a pre-installed Network Management Card 3, dust filter, and installation guide.
- 60kVA / 60kW rated power
- 400V three-phase input and output
- 3:3 UPS configuration
- Double-conversion online topology
- External battery system
- Batteries sold separately
- 5×8 start-up service included
- Pre-installed Network Management Card 3
- EcoStruxure-ready for remote monitoring and management
- Parallel operation of up to 6 UPS units
- Built-in static bypass
- Dust filter included
- IP20 protection
- Touch-screen LCD user interface
- 1-year warranty
Call for Price
- 2 to 3 days-delivery
Speedy and reliable parcel delivery!
For Immediate delivery
For urgent delivery requirements, please contact our sales team. Standard shipping is typically within 2–3 days, with back-to-back orders taking 4–5 weeks. Product images are for illustrative purposes only.
Request a Quote
Documents
Click Here For Product Data Sheet
Product Description
Easy UPS 3M 60kVA/60kW 400V 3:3 UPS (E3MUPS60KHS)
The Easy UPS 3M 60kVA/60kW 400V 3:3 UPS (E3MUPS60KHS) is a high-capacity three-phase online uninterruptible power supply designed to provide dependable power protection and business continuity for small and medium data centers and other business-critical applications. With a 60kVA/60kW capacity, compact design, and robust electrical specifications, it provides continuous power conditioning for demanding three-phase loads.
The UPS uses double-conversion online technology and provides a 3:3 configuration, with three-phase input and three-phase output. It supports 380V, 400V, and 415V three-phase operation, allowing the UPS to be deployed in different electrical environments. Schneider Electric specifies an input connection using a hard-wired 5-wire configuration (3P + N + E).
The E3MUPS60KHS is specifically designed for an external battery system. Unlike Easy UPS 3M models with internal batteries, this configuration is supplied without batteries, allowing customers to select and customize the battery solution according to their required runtime and installation requirements. Compatible battery solutions include lead-acid external battery systems and Schneider Electric identifies compatibility with Galaxy Lithium-ion battery cabinets.
The UPS includes 5×8 start-up service, providing scheduled start-up support as part of the product offering. The supplied equipment also includes a dust filter and installation guide.
For remote monitoring and management, the E3MUPS60KHS is supplied with a pre-installed Network Management Card 3. The Easy UPS 3M platform is EcoStruxure-ready, allowing cloud-based monitoring and management of connected UPS infrastructure.
The Easy UPS 3M 60kVA model supports parallel operation of up to six UPS units for additional capacity or redundancy. This provides scalability for installations where power requirements may increase or where additional system availability is required.
A built-in static bypass provides an alternate power path for the load during appropriate operating or fault conditions. The UPS also features a touch-screen LCD user interface for local monitoring and operation.
The unit has an IP20 protection rating as standard. Schneider Electric also identifies optional IP30, IP40, and IPX2 kits for applications requiring additional enclosure protection.
The Easy UPS 3M 60kVA/60kW 400V 3:3 is therefore suitable for data centers, electrical rooms, industrial facilities, and other business-critical environments where high-capacity three-phase online power protection and a flexible external battery solution are required.
The Schneider Electric Gulf product listing specifies a 12-month warranty for this model.
Key Features
- 60kVA / 60kW power capacity
- 400V three-phase UPS
- 3:3 three-phase input/output configuration
- Double-conversion online technology
- External battery system
- Battery solution customizable to required runtime
- Batteries sold separately
- 5×8 start-up service included
- Pre-installed Network Management Card 3
- EcoStruxure-ready
- Parallel up to 6 UPS units for capacity or redundancy
- Built-in static bypass
- Touch-screen LCD user interface
- Dust filter included
- IP20 standard protection
- Optional IP30, IP40 and IPX2 protection kits
- 1-year warranty
TECHNICAL SPECIFICATIONS
Click Here For Product Data Sheet
| Overview | |
|---|---|
| Presentation | Easy-to-install, easy-to-connect, easy-to-use, and easy-to-service 60 kVA 3 phase UPS with advanced product features, robust electrical specifications and compact design making your business continuity easy. Ideal for small and medium data centers and other business critical applications, this UPS is EcoStruxure-ready to give you peace of mind with cloud-based remote monitoring and management. It is supplied without batteries, so you can easily customize your battery solution. Includes 5×8 start-up service. |
| Main | |
| Main input voltage | 400 V AC 3 phases 380 V AC 3 phases 415 V AC 3 phases |
| Other input voltage | 380 V 415 V |
| Maximum input current | 104 A |
| Max short time withstand current | 10 kA |
| Input harmonic distortion | Less than 3 % for full load |
| Load power factor | 0.5 leading to 0.5 lagging |
| Cos phi | 0.99 |
| Efficiency at full load | 342…477 V |
| Input connection | 1 hard wire 5-wire (3P + N + E) |
| Input frequency | 40…70 Hz |
| Output voltage | 400 V AC 3 phases 380 V AC 3 phases 415 V AC 3 phases |
| Other output voltage | 380 V 415 V |
| Rated power in W | 60 kW |
| Rated power in VA | 60 kVA |
| Bypass type | Built-in static bypass |
| Crest factor | 3 : 1 |
| Harmonic distortion | Less than 3 % |
| Maximum configurable power in VA | 60 kVA |
| Maximum configurable power in W | 60 kW |
| Output harmonic distortion | < 3% linear load and < 5% non-linear load |
| Output overload operation | 10 minutes at 125% and 60 seconds at 150% |
| UPS topology | Double conversion online |
| Waveform type | Sine wave |
| Output frequency | 50 Hz sync to mains 60 Hz sync to mains |
| Complementary | |
| Battery type | Lead-acid external sold separately |
| Control panel | Touch screen LCD user interface |
| Free slot | 1 |
| UPS connectivity | Pre-installed network management card 3 |
| Color | White (RAL 9003) |
| Height | 91.5 cm |
| Width | 36 cm |
| Depth | 85 cm |
| Product weight | 109 kg |
| USB compatible | Yes |
| Provided equipment | Dust filter Installation guide Start-up service |
| Range of product | Easy UPS 3M |
| Product or component type | Uninterruptible power supply (UPS) |
| Environment | |
| Ambient air temperature for operation | 0…40 °C |
| Ambient air temperature for storage | -25…55 °C |
| Storage altitude | 0…15240 m |
| IP protection | IP20 |
| Relative humidity | 0…95 % non-condensing |
| Storage relative humidity | 0…95 % non-condensing |
| Acoustic level | 65 dBA |
| Heat dissipation | 10523 Btu/h |
| Operating altitude | 0…4921 ft |
| Batteries & Runtime | |
| Battery type | External battery system |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 114.000 cm |
| Package 1 Width | 47.500 cm |
| Package 1 Length | 96.500 cm |
| Package 1 Weight | 133.000 kg |
| Contractual warranty | |
| Warranty (in months) | 12 |
