APC Easy UPS On-Line 10kVA/10kW UPS | Tower | 230V | LCD Display | Extended Runtime | Intelligent Card Slot | SRV10KIL

Documents

Click Here For Product Data Sheet

Product Description

APC Easy UPS On-Line SRV10KIL 10000VA/10000W Extended Runtime UPS

The APC Easy UPS On-Line SRV10KIL is a high-performance uninterruptible power supply engineered to deliver continuous power protection for mission-critical applications. Designed for IT professionals and network administrators, it helps maintain business uptime by supplying dependable backup power during utility outages, voltage fluctuations, and other power disturbances.

With a power capacity of 10000VA/10000W, this double-conversion online UPS provides pure sine wave output suitable for sensitive electronic equipment that requires stable, high-quality power. Its online topology continuously conditions incoming utility power, helping protect connected devices from interruptions and electrical anomalies.

The SRV10KIL supports extended runtime operation through the use of external battery packs, making it an ideal solution for applications that require prolonged backup power during extended outages. The tower UPS features hard-wire 3-wire (1P+N+E) input and output connections, enabling integration into professional electrical installations.

For enhanced monitoring and management, the UPS includes an intelligent card slot that supports optional Network Management Cards, including AP9544, SRVSMB001, and VGL9601I. These management options enable network-based UPS monitoring and administration. The UPS can also connect to EcoStruxure IT and third-party centralized management platforms, providing administrators with improved visibility and control over distributed power environments.

The SRV10KIL incorporates both automatic and manual bypass functions, ensuring seamless power delivery to connected equipment even in the event of an internally detected fault or UPS error. This feature helps maintain load availability and minimizes downtime for critical systems.

Designed for demanding environments, the SRV10KIL is well suited for small data centers, manufacturing facilities, computer rooms, network storage devices, telecommunication systems, and healthcare IT applications. The UPS and its built-in lead-acid battery are backed by a 2-year warranty for dependable long-term operation.

Key Features

• 10000VA/10000W double-conversion online UPS with pure sine wave output
• Tower form factor with extended runtime capability using external battery packs
• Hard-wire 3-wire (1P+N+E) input and output connections
• Intelligent card slot for optional Network Management Card support
• Compatible with AP9544, SRVSMB001, and VGL9601I management cards
• Supports EcoStruxure IT and third-party centralized management platforms
• Built-in automatic and manual bypass for seamless power continuity
• 2-year warranty for the UPS and built-in lead-acid battery
