Supermicro CloudDC SYS-621C-TN12R X13 Rack Server | 2x Intel Xeon Silver 4410Y 12-Core 2.0GHz | 128GB DDR5 4800MHz RAM | 12x Hybrid NVMe/SATA/SAS Bays | 2x 960GB NVMe M.2 | Intel X710 10GbE | Dual 1200W Titanium PSU | TPM 2.0 | 621C-TN12R-OTO-40

Supermicro CloudDC SYS-621C-TN12R X13 (621C-TN12R-OTO-40) Rack Server

The Supermicro CloudDC SYS-621C-TN12R X13 (621C-TN12R-OTO-40) is a powerful 2U rack server designed for modern cloud infrastructure, virtualization, enterprise applications, and data center deployments. Its dual-socket architecture, high-speed DDR5 memory, flexible hybrid storage, 10GbE networking, redundant power supplies, and hardware security features provide a balanced platform for demanding computing environments.

At the core of this configuration are two Intel Xeon Silver 4410Y processors, each featuring 12 cores and a 2.0GHz base frequency. With a total of 24 physical CPU cores, the dual-processor configuration is designed to handle highly parallel workloads and multiple concurrent applications, making the server suitable for virtualization, cloud services, database workloads, and enterprise infrastructure.

The system includes 128GB of DDR5 4800MHz memory, providing high memory bandwidth for compute-intensive applications and virtualized environments. The X13 platform is built around the Intel Xeon Scalable processor architecture and supports substantial memory expansion, allowing organizations to scale system memory as workload requirements increase.

Storage flexibility is a key feature of the SYS-621C-TN12R. The server provides 12 hybrid NVMe/SATA/SAS drive bays, allowing organizations to select the appropriate storage technology for performance, capacity, and workload requirements. The configuration also includes 2x 960GB NVMe M.2 drives, providing fast solid-state storage suitable for operating systems, applications, boot environments, or other high-speed storage requirements.

For high-speed network connectivity, this configuration includes an Intel X710 10GbE network adapter. 10Gb Ethernet provides substantially greater network bandwidth than conventional Gigabit Ethernet and is well suited to virtualization clusters, storage networks, cloud infrastructure, high-performance file services, and data center applications.

Power redundancy is provided by dual 1200W Titanium power supplies. The redundant power architecture allows the server to maintain operation in the event of a power supply failure when connected to appropriate independent power sources, helping improve availability in critical data center environments.

The system also incorporates TPM 2.0 hardware security technology, providing a trusted hardware foundation for security-related functions such as platform integrity and cryptographic operations. This is particularly useful in enterprise environments where hardware-based security and trusted computing capabilities are important.

As part of Supermicro’s CloudDC X13 family, the SYS-621C-TN12R is designed around the needs of modern data center and cloud deployments. Its combination of dual-socket compute, DDR5 memory, flexible NVMe/SAS/SATA storage, 10GbE networking, redundant Titanium power supplies, and TPM 2.0 makes it a versatile platform for organizations requiring scalable and reliable server infrastructure.

The Supermicro CloudDC SYS-621C-TN12R X13 (621C-TN12R-OTO-40) is therefore well suited for virtualization, private and public cloud infrastructure, enterprise applications, databases, software-defined storage, high-performance file services, and other demanding data center workloads.

Key Features

• Supermicro CloudDC X13 SYS-621C-TN12R platform
• 2x Intel Xeon Silver 4410Y processors
• 12 cores per processor, 24 total CPU cores
• 2.0GHz processor base frequency
• 128GB DDR5 4800MHz memory
• 12x hybrid NVMe/SATA/SAS drive bays
• 2x 960GB NVMe M.2 drives
• Intel X710 10GbE networking
• 2x 1200W Titanium redundant power supplies
• TPM 2.0 hardware security
• 2U rackmount form factor
• Suitable for cloud computing, virtualization, databases and enterprise workloads
