Dell Power Edge Servers T560,Intel Xeon SIlver 4410Y 2G/16GB UDIMM,480GB SSD SATA 3Yr ProSupport and NBD On-Site Service
17,250.00 AED Excl. of Tax
- 2 to 3 days-delivery
Speedy and reliable parcel delivery!
For Immediate delivery
For urgent delivery requirements, please contact our sales team. Standard shipping is typically within 2–3 days, with back-to-back orders taking 4–5 weeks. Product images are for illustrative purposes only.
Request a Quote
Features & Design
PowerEdge T560 tower server resources
Innovate where you never thought possible
Office-friendly and hyper-capable
Find your balance
Experience balanced expandability and performance for enterprise-level workloads.
- Database applications with expanded storage with up to 12×3.5” drives and faster I/O with PCIe Gen5
- Virtualization and AI inferencing with up to two Xeon Scalable processors, DDR5 memory, and up to 6 GPUs
- Office settings and applications with easy deployment and quiet acoustics
- Enterprise-level security requirements with cyber-resilience to store, process and analyze data
Made to scale
- Maximize your performance with up to 50% faster 5th Generation Intel processors, doubled bandwidth DDR5, doubled speed PCIe Gen 5, and doubled performance on PERC12
- Flexible and balanced storage capacity with up to 12×3.5’’ or 24×2.5’’ drives, allowing a mix of HDD, SSD, and NVMe support
- Provide mainstream datacenter level cyber-resiliency to store, process, and analyze data in a small footprint
Tech Specifications
Processor
Up to two 4th Generation Intel® Xeon Scalable processor, with up to 32 cores per processor
Up to two 5th Generation Intel® Xeon Scalable processor, with up to 28 cores per processor
Operating System
Canonical Ubuntu Server LTS
Microsoft Windows Server with Hyper-V
RedHat Enterprise Linux
SUSE Linux Enterprise Server
VMware ESXi
Chipset
Intel® C741 Chipset
Accelerators
Up to 2 x 300 W DW and 6 x 75 W SW
Memory
DIMM Speed
Speeds up to 4800 MT/s on the 4th Generation Intel® Xeon Scalable processor
Speeds up to 5200 MT/s on the 5th Generation Intel® Xeon Scalable processor
Memory Type
RDIMM
Memory Module Slots
16 DDR5 DIMM slots
Maximum RAM
RDIMM 1 TB
Storage
Front Bay
Up to 12 x 3.5-inch SAS/SATA HDD drives, max 180 TB
Up to 8 x 3.5-inch SAS/SATA HDD drives, max 120 TB
Up to 8 x 3.5-inch SAS/ SATA HDD + 8 x 2.5-inch NVMe SSD drives, max 240 TB
Up to 8 x 2.5-inch SAS/SATA HDD drives, max 120 TB
Up to 16 x 2.5-inch SAS/SATA HDD drives, max 240 TB
Up to 24 x 2.5-inch SAS/SATA HDD drives, max 360 TB
Mid Bay
N/A
Rear Bay
N/A
Storage Controllers
Internal Controllers
HBA465i, HBA355i, H755, H755N, H355, H965i
External Controllers
HBA355e
Software RAID
S160 (NVMe only)
Internal Boot
Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs
USB
Security
Cryptographically signed firmware
Data at Rest Encryption (SEDs with local or external key mgmt)
Secure Boot
Secure Erase
Secured Component Verification (Hardware integrity check)
Silicon Root of Trust
System Lockdown (requires iDRAC9 Enterprise or Datacenter)
TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Management
Embedded / At-the-Server iDRAC9
iDRAC9
iDRAC Direct
iDRAC RESTful API with Redfish
iDRAC Service Module
Quick Sync 2 wireless module
Consoles
OpenManage Enterprise
OpenManage Power Manager plugin
OpenManage Service plugin
OpenManage Update Manager plugin
CloudIQ for PowerEdge plug in
OpenManage Enterprise Integration for VMware vCenter
OpenManage Integration for Microsoft System Center
OpenManage Integration with Windows Admin Center
Mobility
OpenManage Mobile
Tools
Dell Repository Manager
Dell System Update
Enterprise Catalogs
iDRAC RESTful API with Redfish
IPMI
RACADM CLI
OpenManage Integrations
BMC Truesight
Microsoft System Center
OpenManage Integration with ServiceNow
RedHat Ansible Modules
Terraform Providers
VMware vCenter and vRealize Operations Manager
Power Supplies
600 W Platinum 100-240 VAC/240 VDC
700 W Titanium 200-240 VAC/240 VDC
800 W Platinum 100-240 VAC/240 VDC
1100 W Titanium 100-240 VAC/240 VDC
1100 W DC/-48-(-60) V
1400 W Platinum 100-240 VAC/240 VDC
1400 W Titanium 100-240 VAC/240 VDC
1400 W Titanium 277 VAC/336 VDC
1800 W Titanium 200-240 VAC/240 VDC
2400 W Platinum 100-240 VAC/240 VDC
2800 W Titanium 200-240 VAC/240 VDC
Ports
Network Options
2 x 1GbE LOM on Planar
1 x OCP x8 card 3.0
Note: The system allows both LOM on planar and OCP card to be installed on the system.
Front Ports
1 x iDRAC Direct (Micro-AB USB) port
1 x USB 2.0
1 x USB 3.0
Rear Ports
1 x Dedicated iDRAC (RJ-45) port
1 x USB 2.0
1 x USB 3.0
1 x Serial (optional)
1 x VGA
2 x Ethernet ports
Internal Ports
1 x USB 3.0 (optional)
Slots
PCIe
Up to 6 PCIe slots:
Slot 1: x16 Gen5 Full height, full length
Slot 2: x16 Gen5 Full height, full length
Slot 3: x16 Gen4 Full height, half length
Slot 4: x16 Gen4 Full height, half length
Slot 5: x16 (with x8 lanes) Gen4 Full height, half length
Slot 6: x16 Gen4 Full height, half length
Bezel
Security bezel
Form Factor
4.5U tower server
Dimensions & Weight
Height
18.26 inches (464.0 mm) with feet
17.60 inches (446.0 mm) without feet
20.03 inches (508.8 mm) with caster wheels
Width
7.87 inches (200.0 mm)
Depth
26.70 inches (678.2 mm) with bezel
26 inches (660.6 mm) without bezel
Weight
107.32 lbs. (Max 48 kg)
