APC Smart-UPS SRT 8000VA/8kW RM 230V | 6U Rackmount | Pure Sine Wave | LCD | Network Management | Rail Kit Included | 3-Year Warranty | SRT8KRMXLI
The APC Smart-UPS SRT 8000VA/8kW RM 230V (SRT8KRMXLI) is a high-capacity double-conversion online UPS designed to provide reliable, regulated power protection for critical IT infrastructure. This 6U rackmount UPS delivers 8000VA/8000W with pure sine wave output and features an LCD interface, network management capability, and extended runtime support. The UPS includes a rack mounting rail kit and is suitable for servers, storage systems, networking equipment, and other critical applications.
- 8000VA / 8000W capacity
- 230V input
- 230V / 400V output
- Double-conversion online topology
- Pure sine wave output
- 6U rackmount form factor
- LCD interface
- Network management capability
- Extended runtime support
- Rail kit included
- Replacement battery available
- 3-year UPS hardware warranty
- 2-year battery warranty
20,277.00 AED Excl. of Tax
- 2 to 3 days-delivery
Speedy and reliable parcel delivery!
For Immediate delivery
For urgent delivery requirements, please contact our sales team. Standard shipping is typically within 2–3 days, with back-to-back orders taking 4–5 weeks. Product images are for illustrative purposes only.
Request a Quote
Documents
Click Here For Product Data Sheet
Product Description
APC Smart-UPS SRT 8000VA/8kW RM 230V (SRT8KRMXLI)
The APC Smart-UPS SRT 8000VA/8kW RM 230V (SRT8KRMXLI) is a high-capacity online uninterruptible power supply designed to protect critical IT infrastructure from power interruptions, voltage fluctuations, and other electrical disturbances. With an 8000VA/8000W capacity, double-conversion online topology, and pure sine wave output, it provides clean and regulated power for demanding business and IT environments.
The double-conversion online architecture continuously conditions incoming electrical power and supplies regulated output power to connected equipment. The pure sine wave output makes the UPS suitable for sensitive electronic equipment and critical IT loads that require stable power quality.
The SRT8KRMXLI features a 6U rackmount form factor, making it suitable for installation in compatible server and network racks. The unit is supplied with the rack mounting rail kit, simplifying rack installation. Schneider Electric identifies this model as an 8kVA rackmount Smart-UPS with a 6U form factor.
The UPS supports 230V input and 230V/400V output configurations, making it suitable for applications requiring higher-voltage output distribution. Its 8000VA/8000W rating provides substantial capacity for servers, storage equipment, networking infrastructure, telecommunications equipment, and other critical loads.
An integrated LCD interface provides local visibility into UPS operating status, measurements, alarms, and other system information. The UPS also supports network-based monitoring and management, allowing IT administrators to remotely monitor UPS operation and power conditions.
The SRT8KRMXLI supports extended runtime through compatible external battery packs. This allows organizations to increase available battery runtime for installations where longer power autonomy is required during prolonged outages. A replacement battery is also available for long-term serviceability.
The APC Smart-UPS SRT 8000VA/8kW RM 230V is designed for critical IT and business applications where high-capacity online power protection, rackmount installation, network management, and extended runtime capability are required.
The SRT8KRMXLI is covered by a 3-year warranty for the UPS hardware and a 2-year warranty for the battery, in accordance with Schneider Electric’s Smart-UPS warranty policy for SRT models.
Key Features
- 8000VA / 8000W power capacity
- 230V input
- 230V / 400V output
- Double-conversion online UPS technology
- Pure sine wave output
- 6U rackmount design
- Rail kit included
- LCD interface
- Network management capability
- Extended runtime support
- Replacement battery available
- Designed for critical IT infrastructure
- 3-year UPS hardware warranty
- 2-year battery warranty
TECHNICAL SPECIFICATIONS
Click Here For Product Data Sheet
Overview |
|
|---|---|
| Presentation | High density, double-conversion on-line power protection with scalable runtime. |
Main |
|
| Run time for load | W — Min-max: 800-8000 W — 5min 14s |
| Max. Capacity Used | 100 % |
| Main input voltage | 220 V AC 1 phase 230 V AC 1 phase 240 V AC 1 phase 380 V AC 3 phases 400 V AC 3 phases 415 V AC 3 phases |
| Other input voltage | 220 V 240 V 380 V 415 V |
| Efficiency at full load | 100…275 V adjustable (half load) 173…476 V adjustable (half load) |
| Input connection | 1 hard wire 3-wire (1P + N + E) 1 hard wire 5-wire (3P + N + E) |
| Input frequency | 40…70 Hz auto-sensing |
| Output voltage | 220 V 1 phase 230 V 1 phase 240 V 1 phase |
| Other output voltage | 220 V 240 V |
| Rated power in W | 8000 W |
| Rated power in VA | 8000 VA |
| Output connection | 6 IEC 60320 3 IEC Jumpers 4 IEC 60320 |
| Output connection | Hard wire 3-wire (H N + E) for 1 zone(s) |
| Bypass type | Internal bypass (automatic and manual) |
| Crest factor | 3 : 1 |
| Harmonic distortion | Less than 2 % |
| Maximum configurable power in VA | 8000 VA |
| Maximum configurable power in W | 8000 W |
| UPS topology | On-Line |
| Waveform type | Sine wave |
| Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
| Replacement battery | APCRBC140 |
Graphs |
|
| Run Time | View Runtime Graph |
| Efficiency | View Efficiency Graph |
Complementary |
|
| Battery type | Lead-acid internal included |
| Emergency power off | Yes |
| Free slot | 1 |
| Preinstalled device | Network management card 3 with environmental monitoring |
| Alarm | Audible and visible alarms : prioritized by severity |
| UPS connectivity | Serial port USB port Embedded network management card 3 Available expansion slot |
| Surge energy rating | 480 J |
| Number of rack unit | 6U |
| Color | Black |
| Height | 263 mm |
| Width | 432 mm |
| Depth | 715 mm |
| Product weight | 111.82 kg |
| Mounting location | Front |
| Mounting preference | No preference |
| Mounting mode | Rack-mounted |
| Two post mountable | 0 |
| USB compatible | Yes |
| Mounting mode | Rack-mounted with included kit |
| Provided equipment | CD with software Documentation CD Installation guide Rack mounting hardware Rack mounting brackets Rack mounting support rails Temperature probe USB cable Warranty card Web/SNMP management card |
| Number of power module filled slots | 0 |
| Number of power module free slots | 0 |
| Additional specification | High density |
| Redundant | No |
| Range of product | Smart-UPS On-Line |
| Product or component type | Uninterruptible power supply (UPS) |
Environment |
|
| Product certification | CE EAC IRAM RCM VDE |
| Marking | CE Mark |
| Standard | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
| Ambient air temperature for operation | 0…40 °C |
| Ambient air temperature for storage | -15…45 °C |
| Storage altitude | 0…15240 m |
| IP protection | IP20 |
| Relative humidity | 0…95 % non-condensing |
| Storage relative humidity | 0…95 % non-condensing |
| Acoustic level | 55 dBA |
| Heat dissipation | 1497 Btu/h |
| Operating altitude | 0…10000 ft |
Batteries & Runtime |
|
| Battery type | Lead-acid battery |
| Battery voltage | +/- 192 V (split battery referenced to neutral) |
| Extendable runtime | 1 |
| Included battery module | 0 |
| Typical recharge time | 1.5 h |
| RBC quantity | 2 |
| Battery life | 3…5 year(s) |
| Battery charging power | 876 W rated |
Packing Units |
|
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 46.1 cm |
| Package 1 Width | 60 cm |
| Package 1 Length | 100 cm |
| Package 1 Weight | 130 kg |
Contractual warranty |
|
| Warranty (in months) | 24 Battery | 36 UPS |
